CV/SV to HDMI Converter with Audio Input
Operates in NTSC 3.58, PAL and SECAM system, Supports output resolution:PC resolution: XGA, SXGA, UXGAComponent resolutions: 480p, 576p, 720p@50/60, 1080p@50/60Note: Component resolution frame rate conversion supports output at 50 to 60Hz only. PC resolution supports frame rate output at 60Hz only., 3D (frame based) motion adaptive YNR/CNR noise reduction and de-interlace, Automatic 2:2 & 3:2 film mode detection, Plug and Play design, easy to setup and no driver software required
| Hersteller-Nr. | CM-398HN |
| Hersteller | Cypress Technology |
This Video to HDMI converter box can convert Composite Video or S-Video (NTSC, PAL or SECAM system) signals to a HDMI output. The device provides a full range of output resolutions, up to 1080p for HDTV resolutions, and UXGA for PC resolutions. With the use of the 3.5mm audio input, stereo audio may be embedded with video selection. Additionally, it features frame rate conversion, allowing users to view DVD, VCR or video game sources on an HD monitor or TV. Users can easily select the output resolution via switch on the unit.
|
Interfaces |
|
|
Input Port |
1×Composite Video(RCA) 1×S-Video(4-Pin mini-DIN) 1×Analog Stereo (3.5mm) |
|
Output Port |
1×HDMI (Type-A) |
|
Video |
||
|
HDMI Compliance |
HDMI 1.2 (DVI 1.0) |
|
|
HDCP Compliance |
N/A |
|
|
Input Signal Type |
Composite Video / S-Video |
|
|
Output Signal Type |
HDMI |
|
|
Interface |
Resolutions |
|
|
Maximum Input |
Composite Video/S-Video |
480i@60 / 576i@50 |
|
Maximum Output |
HDMI |
1920x1080p@60Hz |
|
Power |
|
|
Power Supply |
5V/1.2A |
|
Power Consumption |
2.5W |
|
Enclosure |
|
|
Chassis Material |
Plastic |
|
Chassis Color |
Black |
|
Dimensions (W×H×D) |
162.6mm×33.5mm×164.5mm [Case Only] 162.6mm×33.5mm×164.5mm [All Inclusive] |
|
Weight |
100g |
|
Field Firmware Update |
|
ORDERING INFORMATION |
|
Model No. |
Product Description |
|
CM-398HN |
CV/SV to HDMI Converter with Audio Input |
